Public Bath House
ArchitectDesigned by
John J. McMahon
American, 1875 - 1958
ArchitectDesigned by
Frank W. Whiton
ArchitectDesigned by
Whiton & McMahon
American
Date1912-1913
MediumDrawings; pencil on tracing paper
DimensionsPrimary Dimensions (image height x width): 19 x 16 7/8in. (48.3 x 42.9cm) or smaller
Sheet (height x width): 25 x 23 1/4in. (63.5 x 59.1cm) or smaller
Sheet (height x width): 25 x 23 1/4in. (63.5 x 59.1cm) or smaller
ClassificationsGraphics
Credit LineGift of Paul R. McMahon, Jr.
DescriptionSketch elevations and floorplans of a public bath house show a one-story building with a bracketed hip roof. A sign over four banked windows on the front facade reads "PUBLIC BATHS" and over each of two arched entry doors are signs that read "MEN" and "WOMEN". The first floor plan includes numerous shower and changing rooms, toilets, offices, and bench seating. The cellar is largely unexcavated, but includes a heater room and a coal bin.
Object number2005.149.12.1-.4
InscribedOn recto, lower right, in pencil, "130". 2005.149.12.3, on recto, center, in pencil, "FIRST FLOOR".
2005.149.12.4, on recto, center, in pencil, "CELLAR AND FOUNDATION PLAN".
On verso, lower right, in pencil, accession numbers.NotesSubject Note: The Public Bath House was designed in 1912 for Pope Park at Park Street and Park Terrace, Hartford, Connecticut.
