Floor Plan for Joiner of St. Stephen's Church, East Haddam, Connecticut
Image Not Available for Floor Plan for Joiner of St. Stephen's Church, East Haddam, Connecticut

Floor Plan for Joiner of St. Stephen's Church, East Haddam, Connecticut

ArchitectDesigned by David R. Brown
Dateabout 1875
MediumDrawing; brown ink and watercolor on treated linen
DimensionsPrimary Dimensions (image height x width): 20 x 10 1/2in. (50.8 x 26.7cm)
Sheet (height x width): 24 1/2 x 18in. (62.2 x 45.7cm)
ClassificationsGraphics
Credit LineGift of John F. Page
DescriptionFloor plan of a church includes sanctuary, kneeling step, organ, vestry, vestibule, porches, pulpit, sliding doors, Sunday school, concrete walk.
Object number2002.147.1
InscribedOn recto, in black ink, upper left: "ST. STEPHEN'S CHURCH. / EAST HADDAM, CONN. / D.R. BROWN, ARCH'T. 70 CHURCH ST. NEW HAVEN, CONN.", upper center: "STREET FRONT", lower right: "FIRST FLOOR / QUARTER SCALE / FOR JOINER." Other inscribed labels include: "SANCTUARY" "VESTRY" "PORCH" "CHANCEL" "VESTIBULE" "ORGAN" "ORGANIST" "LECTURN" "RAILING" "STEP" "PULPIT" "PAIR OF DOORS" "STONE COPING" "SLIDING DOORS" "WEIGHTED DOOR / GLAZED" "ENTERING PORCH" "SUNDAY SCHOOL" "CONCRETE WALK" "NORTH LINE OF LOT"
